2L Acrylic & Stainless Steel 304 Clear Pressure Vessel with Agitation
2L Acrylic & Stainless Steel 304 Clear Pressure Vessel with Agitation
The CTEL series clear pressure vessels with agitation by electric motor are specifically designed to suit fluids requiring gentle stir, fast or programmed agitation.
Made to work in both busy factories and research labs, the reservoirs can provide intermittent or constant agitation.
All compact agitated pressure reservoirs are exclusively made of stainless steel grade 303 and clear acrylic cylinders.
This ensures that the material contents are not contaminated by corrosion. CT Tanks Series can operate to 28°C.
|
Type
|
CTEL |
|---|---|
|
Volume
|
2 litres |
|
Agitation
|
Electrical |
|
Material
|
Stainless steel 304 / Acrylic |
|
Pressure range
|
0-4 bar (58 psi) |
Max. working pressure: 60psi (4 bar)
Capacity: 2L
Weight: 7.0 kg
Power: 0.3 kW
Voltage: 230AC V
Minimum speed: 40RPM
Maximum speed: 800RPM
Torque: 1.4Nm
Mixing propellers
| Dual blade propellers
Standard blade paddle |
Four blade propellers
Optinal blade paddle |
Three blade propellers
Optinal spiral propellers with |
Anchor blade propellers
Optinal anchor propellers. |
 |
 |
 |
 |
